Product Description
Schaefer Single Cheek Block w/ Curved/Base
03-30 Stainless Steel cheek block with curved base. Fits spar diameters up to 2". Delrin(tm) plain bearing sheave ensure high safe working load and is good for static loads.
Specifications
Sheave Dia.: 1 7/16 in. (37 mm)
Sheave Width: 9/16 in. (14 mm)
Pin Dia.: 3/16 in. (5 mm)
Max Line: 7/16 in. (11 mm)
L: 3 11/16 in. (949 mm)
W: 1 in. (25 mm)
H: 3/4 in. (19 mm)
Fasteners: (4) #10 RH (5 mm)
C/C: 3 3/16 in. (94 mm)
SWL: 1000 lbs. (450 kg)
Weight Stain.: 2.2 oz. (62 g)
