Schaefer Single Block w/Front-Side Shackle Max Line 5/16" (8mm)

Item #

02-03

Usually ships within 1-3 days

Product Description

Schaefer Single Block w/Front-Side Shackle Max Line 5/16" (8mm)

Single block with front-side shackle. Delrin(tm) sheave on plain bearing ensures smooth operation and high static load safe working loads. For boats to 20'.

Specifications

  • Sheave Dia.: 1 1/16 in. (27 mm)

  • Sheave Width: 3/8 in. (9 mm)

  • Pin Dia.: 3/16 in. (5 mm)

  • Thickness: 19/32 in. (15 mm)

  • Width: 1 3/16 in. (30 mm)

  • Length: 3 15/32 in. (88 mm)

  • SWL: 900 lbs. (410 kg)

  • Weight: 1.75 oz (50 g)

  • Max Line: 5/16 in. (8 mm)
